238M THERMAL KIOSK PRINTER

MICROCOM 238M THERMAL KIOSK PRINTER


KEY FEATURES:

PAPER WIDTH
1”-2.25" (25.4 mm-58 mm)

PRINT RESOLUTION
203 dpi or 300 dpi

MAX PRINT SPEED
Up to 8” /second (200 mm)

COMMUNICATION PORTS
USB

FIELD REPLACEABLE WEAR PARTS
Print Head, Drive Roller, Cutter

INDUSTRIES:

Utilize kiosk space wisely with the small form factor of the 238M. A truly industrial quality kiosk printer that can be configured in a variety of ways to accommodate many different types of 2 inch wide paper. Printing bag tags and labels is just as simple as receipt printing for this versatile kiosk mechanism.

238M Features:

  • Guillotine cutter (optional industrial rotary cutter)
  • Easy to replace wear parts
  • Rugged metal design
  • Presenter (optional)
  • High torque motor for thicker stock and larger rolls (optional)
  • Small form factor
  • Auto loading capability
  • Windows print driver for quick and easy integration
  • Microcom LDS programming language
  • Paper up to .013” thick
  • 20MB Flash for storing fonts and graphics
  • 8MB RAM

238M Accessories:

slide2
slide3
slide4
slide5

238M Uses:


  • Live Event Ticketing
  • Promotional Voucher Issue
  • Automated Parking Attendant
  • Receipt Printing
  • Admissions Processing

238M Drivers:


Name Description Category Download
Windows FTDI USB Driver Used for USB connectivity on FTDI chip set printers by utilizing a USB to Virtual Serial Port driver Driver
Windows Print Driver For general Windows printing using Windows print sub system Driver

238M Utilities:


Name Description Category Download
MCT Terminal application for communication with Microcom products Utilities
BMP2MIC Bitmap to Microcom format for graphic creation Utilities

Developer Tools:


Name Description Category Download
Windows Driver Sample Application Used to demo the Microcom Windows driver programmatically | Requires Windows Print Driver Sample Application

Manuals for the 238M and applications:


Name Description Category Download
Windows Print Driver Manual Download and view the manual for the Microcom Windows driver Manual
238M Operators Manual Download and view the operators manual for the Microcom 238M thermal printer Manual
PAPER WIDTH: 1”-2.25" (25.4 mm-58 mm)
PAPER THICKNESS: UP TO .013" (.33 mm)
  • 2" x 5.5” Event Tickets
  • Credit Card Tickets
  • Bag Tags
  • Continuous Receipt Roll
    (up to 2.25” wide)
  • Die-Cut Labels


*Don't see what you're looking for? Contact sales at sales@microcomcorp.com or (740) 548-6262*

Request more Information


You may contact us by filling in this form any time you need professional support
or have any questions.



* indicates required field

Request more Information


You may contact us by filling in this form any time you need professional support
or have any questions.



* indicates required field

[INSTRUCTIONS FOR USB CONNECTED PRINTERS | IF USING ETHERNET, SKIP TO DOWNLOAD]




NOTE: The FTDI USB Driver is located in the Windows Driver Zip File



Connecting printer & powering it on will cause OS to search for appropriate driver. | If OS is unable to find the driver, follow instructions below to manually install the driver.


  Quick Steps:

  1. If using the USB port; Connect and power on the printer.

    2.
  2. If the Operating System fails to install the USB driver, run the CDM20814_Setup.exe (FTDI USB Driver) to manually install the USB port.

    3.
  3. Once the FTDI USB Driver is installed, disconnect the USB and then reconnect it before installing the Windows Print Driver.

    4.
  4. If using the Windows printer driver, please run the Microcom Print Driver installer; Setup-2.X.X.XX.exe.

    5.


  **For more detailed information, please consult the appropriate driver install manual.


Download Windows Driver




[FOR USE WITH MODELS: 438,438TC,438T,438TM,238M,238ML,338M,AND 334M]
